STTModule

The Speech-to-Text module enables voice dictation using the Web Speech API. Allows users to dictate text directly into the editor with real-time audio visualization.

Note: The Speech-to-Text module requires a browser that supports the Web Speech API (Chrome, Edge, Safari). If the API is not available, the module will display a disabled state with an appropriate message.

Options

option name	type	description	default value	possible values
language	string	Speech recognition language in BCP 47 format (e.g., 'en-US', 'fr-FR', 'es-ES')	'en-EN'	Any valid BCP 47 language code
continuous	boolean	If true, recognition automatically restarts after each pause. If false, user must manually restart	false	true, false
visualizer	boolean	Display animated audio visualizer (equalizer with 14 columns) reflecting microphone input in real-time	true	true, false
waveformColor	string	Gradient secondary color for the audio visualizer (top part of columns)	'#4285f4'	Any valid CSS color (hex, rgb, etc.)
histogramColor	string	Primary/accent color used for visualizer gradient, toolbar button when active, and listening label	'#25D366'	Any valid CSS color (hex, rgb, etc.)
debug	boolean	Enable debug mode to display recognition logs and events in browser console	false	true, false
buttonTitleStart	string	Tooltip text shown on microphone button hover when recognition is inactive	'Start listening'	Any string
buttonTitleStop	string	Tooltip text shown on microphone button hover when recognition is active	'Stop listening'	Any string
titleInactive	string	Label text displayed in the STT bar when recognition is inactive	'Inactive'	Any string
titleStarting	string	Label text displayed in the STT bar when recognition is initializing	'Starting...'	Any string
titleActive	string	Label text displayed in the STT bar during active listening	'Listening...'	Any string

Usage example

use Ehyiah\QuillJsBundle\Form\QuillType;
use Ehyiah\QuillJsBundle\DTO\Modules\STTModule;

public function buildForm(FormBuilderInterface $builder, array $options)
{
    $builder
        ->add('content', QuillType::class, [
            'quill_options' => [
                QuillGroup::buildWithAllFields()
            ],
            'modules' => [
                new STTModule(
                    language: 'fr-FR',           // French language recognition
                    continuous: true,             // Auto-restart after pauses
                    visualizer: true,             // Show audio visualizer
                    waveformColor: '#4285f4',     // Blue gradient color
                    histogramColor: '#25D366',    // Green accent color
                    debug: false,                 // Disable debug logs
                    buttonTitleStart: 'Start voice dictation',
                    buttonTitleStop: 'Stop voice dictation',
                    titleInactive: 'Voice recognition inactive',
                    titleStarting: 'Initializing...',
                    titleActive: 'Listening to your voice...',
                ),
            ],
        ])
    ;
}
